200/3 Horizontal Pipe Stranding Machine

Main Specifications:

Winding machine part:

Headstock form: fixed

Cable stroke: ≤100mm

Swing diameter: ＜φ48mm

Range of wire diameters that can be wound: 0.04-0.14mm (larger wire diameter can be applied to increase the motor power)

power supply: Single-phase AC220V (±5%), 50Hz

Gas source: 0.5-0.6 Mpa

Spindle:

Number of spindles: 6-8-10-12-16

Spindle spacing: 48mm

Main motor: AC Servo 1.5KW

Spindle positioning accuracy: ≤±0.36°

Spindle speed: 0-12000rpm

3D mobile device:

Motor: AC Servo 200W

3D stroke: X≤85mm; Y≤85mm; Z≤55mm

Moving speed: ≥100cm/sec

Wrapping position: 0°, 90°

Repeatability: ≤±0.01mm
